Compact and Full-featured VDSL2 Technology
Compliant with ITU-T G.993.2, G994.1 and G.997.1
The VES1724 conforms to G.993.2, G994.1 and G.997.1 to ensure the interoperability with standard-compliant VDSL CPE.
Ultra high-speed transmission with 30a profile support
The VES1724 supports 30a profile with 100 Mbps in both upstream and downstream traffics. With two Gigabit combo ports to connect upper layer aggregation networks, the VES1724 can support low-concentration interconnection from the subscriber ports to the network interface ports.
Triple Play ready
The VES1724 supports IGMP snooping to prevent unnecessary forwarding of multicast traffic to all subscribers and thus optimizes bandwidth utilization for multicast applications such as broadcast video. The VES1724 also supports the multicast VLAN feature that distributes the source to all the VLANs requesting the video stream. With a built-in splitter over POTS, the VES1724 allows the operators to provide Triple Play services over the same copper wire.
Complete QoS for service differentiation
The VES1724 supports not only 802.1X port-based access control for subscriber authentication, but also defines a limited number of MAC addresses that can access the network from a particular port. With rate limiting on the subscriber ports allowing services to take advantage of 64 Kbps increments, service providers will be in a better position to offer tiered services.
Products specifications
| Width | 440 mm |
| Depth | 250 mm |
| Height | 44.4 mm |
| Weight | 4.7 kg |
| Harmonized System (HS) code | 85176990 |
| AC adapter included | Yes |
| Package type | Box |
| Package width | 550 mm |
| Package depth | 395 mm |
| Package height | 175 mm |
| Package weight | 5.3 kg |
| Operating temperature (T-T) | -40 - 65 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| AC input voltage | 100 - 264 V |
| Power consumption (typical) | 63 W |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| MIB support | Y |
| Power connector | DC-in jack |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p |
| MAC address table | 1600 entries |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Wall mountable | Yes |
| User guide | Yes |
| Manual | Yes |
| MAC address filtering | Yes |
| Multicast support | Yes |
