Enjoy the most natural interactive digital experience
Modern meeting spaces drive the demand for advanced touch technology with innovative design. To support interactive sessions, the NEC InGlassTM Touch Board along with the responsive passive pen brings superior paper-like writing with minimal latency to a digital canvas. With its slim bezel design, the technology seamlessly integrates into modern interior styling.
High brightness levels ensure excellent readability and image reproduction even in today’s typically bright meeting spaces where maintaining a motivational environment is paramount. The anti-glare coating minimizes disturbing reflections and helps to eliminate niggling fingerprints on the touch surface.
Products specifications
| Width | 1501.3 mm |
| Depth | 73.2 mm |
| Height | 879 mm |
| Weight | 53.5 kg |
| Maximum refresh rate | 60 Hz |
| Manual | Yes |
| Mobile operating systems supported | Android |
| USB 2.0 ports quantity | 1 |
| Mac compatibility | Yes |
| Package width | 1736 mm |
| Package depth | 280 mm |
| Package height | 1033 mm |
| Package weight | 65 kg |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Power consumption (standby) | 2 W |
| Power consumption (max) | 120 W |
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 116 kWh |
| Energy consumption (HDR) per 1000 hours | 105 kWh |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 1 |
| USB port | Yes |
| USB ports quantity | 1 |
| USB version | 2.0 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100 Mbit/s |
| Product design | Interactive flat panel |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| Anti-glare screen | Yes |
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | No |
| Panel type | IPS |
| LED backlighting type | Direct-LED |
| Display diagonal | 165.1 cm (65") |
| Display technology | LCD |
| Display resolution | 3840 x 2160 pixels |
| Display brightness | 500 cd/m² |
| HD type | 4K Ultra HD |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 20 |
| Native aspect ratio | 16:9 |
| Response time | 8 ms |
| Contrast ratio (typical) | 8000:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Horizontal scan range | 26 - 91.1 kHz |
| Vertical scan range | 23 - 86 Hz |
| Hardness | 7H |
| Haze rate | 5% |
| Remote control included | Yes |
| Batteries included | Yes |
| Number of stylus pens | 2 |
| Cables included | HDMI, Power |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Linux operating systems supported | Yes |
