Width
|
215 mm |
Depth
|
117 mm |
Height
|
32 mm |
Maximum data transfer rate
|
1 Mbit/s |
Harmonized System (HS) code
|
85176990 |
Package width
|
350 mm |
Package depth
|
240 mm |
Package height
|
82 mm |
Package weight
|
870 g |
Package type
|
Box |
Operating temperature (T-T)
|
0 - 40 °C |
Storage temperature (T-T)
|
-40 - 70 °C |
Operating relative humidity (H-H)
|
10 - 90% |
Storage relative humidity (H-H)
|
5 - 90% |
Power source type
|
AC |
Output voltage
|
12 V |
Output current
|
1 A |
Reset button
|
Yes |
WPS push button
|
Yes |
Ethernet LAN (RJ-45) ports
|
5 |
USB port
|
No |
Memory card slot(s)
|
No |
DC-in jack
|
Yes |
Ethernet LAN
|
Yes |
Ethernet LAN interface type
|
Fast Ethernet |
Ethernet LAN data rates
|
10,100 Mbit/s |
Cabling technology
|
10/100Base-T(X) |
Networking standards
|
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Port forwarding
|
Yes |
VPN Passthrough
|
Yes |
VPN support
|
PPTP, L2TP, IPSec |
Receiver sensitivity
|
5GHz: 11a 54M: -76dBm
11ac VHT20 MCS8: -70dBm
11ac VHT40 MCS9: -65.5dBm
11ac VHT80 MCS9: -61.5dBm
2.4G: 11g 54M: -76dBm
11n HT20 MCS7: -74dBm
11n HT40 MCS7: -71dBm |
Product colour
|
White |
Indication light
|
Yes |
LED indicators
|
LAN, Power, WLAN |
On/off switch
|
Yes |
Product type
|
Tabletop router |
Cables included
|
LAN (RJ-45) |
AC adapter included
|
Yes |
Manual
|
Yes |
Quick installation guide
|
Yes |
Quick start guide
|
Yes |
Windows operating systems supported
|
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
Linux operating systems supported
|
Yes |
Mac operating systems supported
|
macOS |
Mac compatibility
|
Yes |
Security algorithms
|
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
Firewall
|
Yes |
Guest access
|
Yes |
Stateful Packet Inspection (SPI)
|
Yes |
DoS attack prevention
|
Yes |
Filtering
|
Yes |
MAC address filtering
|
Yes |
IP address filtering
|
Yes |
DMZ support
|
Yes |
DHCP client
|
Yes |
DHCP server
|
Yes |
Universal Plug and Play (UPnP)
|
Yes |
VoIP protocols
|
IPv4, IPv6 |
Ethernet WAN
|
Yes |
DSL WAN
|
No |
SIM card slot
|
No |
3G/4G USB modem compatibility
|
No |
WAN connection type
|
RJ-45 |
Wi-Fi band
|
Dual-band (2.4 GHz / 5 GHz) |
Top Wi-Fi standard
|
Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (max)
|
867 Mbit/s |
Wi-Fi standards
|
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
WLAN data transfer rate (first band)
|
450 Mbit/s |
WLAN data transfer rate (second band)
|
867 Mbit/s |
Antenna design
|
External |
Antennas quantity
|
5 |
Transmit power
|
CE: <20dBm(2.4GHz), <23dBm(5GHz) |
3G
|
No |
4G
|
No |
