TP-Link InSight S655I IP security camera Indoor 2560 x 1920 pixels Ceiling/wall

TP-Link InSight S655I. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Housing material: Metal. Lens viewing angle, horizontal: 180°, Lens viewing angle, vertical: 180°, Lens viewing angle, diagonal: 180°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Sensor type (panoramic camera): CMOS, Signal-to-Noise Ratio (SNR) (panoramic camera): 52 dB
Manufacturer: TP-Link
SKU: INSIGHT S655I
Vendor: Aspects
360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display mode, it functions as four cameras at once, delivering complete coverage and flexible perspectives.

Multiple Display Modes
Along with the fisheye view, VIGI provides multiple display modes, enabling you to focus on every detail exactly as you prefer.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
  • Legal warranty via the seller
  • 30 days to change your mind — free returns
  • Free delivery from €25
€372.50 incl tax
increase decrease
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display mode, it functions as four cameras at once, delivering complete coverage and flexible perspectives.

Multiple Display Modes
Along with the fisheye view, VIGI provides multiple display modes, enabling you to focus on every detail exactly as you prefer.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Products specifications
Weight & dimensions
Height56 mm
Diameter13.2 cm
Weight440 g
Operational conditions
Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Power
Power source typeDC, PoE
Power consumption (max)11.76 W
Power consumption (Power over Ethernet (PoE))12.14 W
DC output voltage12
Technical details
Lens mount interfaceM12
Management features
Web browserYes
Cloud-managedYes
Reset buttonYes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Network
Ethernet LANYes
Ethernet interface typeFast Ethernet
Networking standardsIEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Supported network protocolsTCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-FiNo
BluetoothNo
Client interoperabilityUtility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
Number of simultaneous live view channels6 channels
Design
Mounting typeCeiling/wall
Product colourWhite
Housing materialMetal
Protection featuresWeatherproof
International Protection (IP) codeIP67
IK codeIK10
WeatherproofYes
Performance
TypeIP security camera
Placement supportedIndoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Day/night modeYes
Infrared (IR) cut-off filterYes
Dynamic range120 dB
CertificationCE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
Packaging content
Number of cameras1
Security
Password protectionYes
Video motion detectionYes
IP address filteringYes
HTTPS encryptionYes
Alert notification typeE-mail, Push notification
Privacy protectionYes
Motion sensorYes
Digest authenticationYes
Audio
Built-in speaker(s)Yes
Audio system2-way
Sample rate8 kHz
Signal-to-Noise Ratio (SNR)52 dB
Built-in microphoneYes
Number of microphones1
Bit rate range0 - 64 Kbit/s
Storage
Built-in HDDNo
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size512 GB
Camera
Minimum illumination0 lx
Lens viewing angle, horizontal180°
Lens viewing angle, vertical180°
Lens viewing angle, diagonal180°
Camera shutter speed1/3 - 1/10000 s
Number of Privacy masking areas4
Lens system
Detect distance28.8 m
Observe distance12 m
Recognize distance5.7 m
Maximum aperture number2
Identify distance2.8 m
Fixed focal length1.44 mm
Video
Maximum resolution2560 x 1920 pixels
Total megapixels5 MP
Video compression formatsH.264, H.264+, H.265, H.265+
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 1280 x 960, 2048 x 1536 (QXGA), 2560 x 1920
Frame rate30 fps
Video streamingYes
Noise reduction technology3D noise reduction
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate64 Kbps to 6 Mbps
Back Light Compensation (BLC)Yes
Highlight Compensation (HLC)Yes
Digital Wide Dynamic Range (DWDR)Yes
Region of Interest (ROI) encodingYes
Smart IRYes
Image sensor
Optical sensor size25.4 / 2.7 mm (1 / 2.7")
Progressive scanYes
Sensor typeCMOS
Night vision
Night visionYes
Night vision distance10 m
LED typeIR
Number of illumination LEDs4
Infra-red wavelength850 nm
Panoramic camera
Sensor type (panoramic camera)CMOS
Signal-to-Noise Ratio (SNR) (panoramic camera)52 dB
Digital Wide Dynamic Range (DWDR) (panoramic camera)Yes
*
*
*
