TP-Link 1-Port XGS-PON Terminal

Be the first to review this product
TP-Link 1-Port XGS-PON Terminal, Optical network terminal (ONT), White, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE..., G.988, G.9907.1, 10,100,1000,10000 Mbit/s, 10000 Mbit/s
Manufacturer: TP-Link
SKU: XGZ030
Vendor: Aspects
TP-Link 1-Port XGS-PON Terminal. Product type: Optical network terminal (ONT), Product colour: White. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE..., ITU standards: G.988, G.9907.1, Ethernet LAN data rates: 10,100,1000,10000 Mbit/s. Security algorithms: AES. Fiber optic connector: SC/APC. Output voltage: 9 V, Output current: 0.85 A
  • ✔ Legal warranty via the seller
  • ✔ 30 days to change your mind — free returns
  • ✔ Free delivery from €25
€122.63 incl tax
increase decrease
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
TP-Link 1-Port XGS-PON Terminal. Product type: Optical network terminal (ONT), Product colour: White. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE..., ITU standards: G.988, G.9907.1, Ethernet LAN data rates: 10,100,1000,10000 Mbit/s. Security algorithms: AES. Fiber optic connector: SC/APC. Output voltage: 9 V, Output current: 0.85 A
Products specifications
Weight & dimensions
Width120 mm
Depth120 mm
Height27.9 mm
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Power
Output voltage9 V
Output current0.85 A
Certificates
Compliance certificatesCE, Federal Communications Commission (FCC), RoHS
Management features
Web-based managementYes
Reset buttonYes
Ports & interfaces
Fiber ports quantity1
Fiber optic connectorSC/APC
Ethernet LAN (RJ-45) ports1
DC-in jackYes
Network
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
ITU standardsG.988, G.9907.1
Ethernet LAN data rates10,100,1000,10000 Mbit/s
Upstream data rate10000 Mbit/s
Downstream data rate10000 Mbit/s
Transmission distance (max)20 km
VLAN supportYes
QinQ VLAN supportYes
Tagged VLANYes
Design
Product typeOptical network terminal (ONT)
Product colourWhite
LED indicatorsYes
On/off switchYes
Packaging content
AC adapter includedYes
Quantity per pack1 pc(s)
Cables includedLAN (RJ-45)
Quick start guideYes
Security
Security algorithmsAES
Wireless LAN features
Wi-FiNo
*
*
*
