StarTech.com 3 Port 2b 1a Low Profile 1394 PCI Express FireWire Card Adapter

Be the first to review this product
StarTech.com 3 Port 2b 1a Low Profile 1394 PCI Express FireWire Card Adapter. Host interface: PCIe, Output interface: IEEE 1394/Firewire, Expansion card standard: PCIe 1.1. Product colour: Green, Mean time between failures (MTBF): 149905 h. Chipset: Texas Instruments - XIO2213B, Data transfer rate (max): 0.8 Gbit/s. Windows operating systems supported: Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64,..., Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow..., Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2019. Width: 58 mm, Depth: 90 mm, Height: 20 mm
Manufacturer: StarTech
SKU: PEX1394B3LP
Vendor: Aspects
Add 2 native FireWire 800 ports to your low profile/small form factor computer through a PCI Express expansion slot

This 3 Port PCI Express FireWire card comes equipped with a low profile bracket for installation in small form factor PCs, and includes an optional full-size bracket for installation in a standard-sized PC case.

The FireWire card can be installed in a PCIe slot to add two IEEE1394b (FireWire 800 - 9 pin) ports and one IEEE1394a (FireWire 400 - 6 pin) port, providing broad compatibility with a wide range of FireWire devices (e.g. DV camcorders, external hard drives, digital cameras, etc.).

The 2x FireWire 800 and 1x FireWire 400 card features a native (single chip) PCI Express chipset, which provides faster, more reliable and cost-effective performance than expansion cards that utilize a "bridge" chip.

The StarTech.com Advantage
  • ✔ Legal warranty via the seller
  • ✔ 30 days to change your mind — free returns
  • ✔ Free delivery from €25
€64.30 incl tax
Lowest price in the last 30 days: $64.30
increase decrease
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Add 2 native FireWire 800 ports to your low profile/small form factor computer through a PCI Express expansion slot

This 3 Port PCI Express FireWire card comes equipped with a low profile bracket for installation in small form factor PCs, and includes an optional full-size bracket for installation in a standard-sized PC case.

The FireWire card can be installed in a PCIe slot to add two IEEE1394b (FireWire 800 - 9 pin) ports and one IEEE1394a (FireWire 400 - 6 pin) port, providing broad compatibility with a wide range of FireWire devices (e.g. DV camcorders, external hard drives, digital cameras, etc.).

The 2x FireWire 800 and 1x FireWire 400 card features a native (single chip) PCI Express chipset, which provides faster, more reliable and cost-effective performance than expansion cards that utilize a "bridge" chip.

The StarTech.com Advantage
Products specifications
Features
ChipsetTexas Instruments - XIO2213B
Data transfer rate (max)0.8 Gbit/s
Plug and PlayYes
Weight & dimensions
Width58 mm
Depth90 mm
Height20 mm
Weight43 g
Logistics data
Harmonized System (HS) code84733020
Products per master (outer) case28 pc(s)
Master (outer) case width331 mm
Master (outer) case length504 mm
Master (outer) case height237 mm
Packaging data
Cables includedFireWire
Mounting brackets includedYes
ManualYes
Package width175 mm
Package depth144 mm
Package height32 mm
Package weight200 g
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-20 - 90 °C
Operating relative humidity (H-H)0 - 90%
Technical details
Sustainability complianceYes
Compliance certificatesCE, RoHS
Ports & interfaces
Host interfacePCIe
Output interfaceIEEE 1394/Firewire
Expansion card standardPCIe 1.1
Firewire (IEEE 1394) ports3
FireWire 400 ports quantity1
FireWire 800 ports quantity2
Design
InternalYes
Product colourGreen
Mean time between failures (MTBF)149905 h
Hot-swapYes
System requirements
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 11, Windows 11 x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2019
*
*
*
Products specifications
Features
ChipsetTexas Instruments - XIO2213B
Data transfer rate (max)0.8 Gbit/s
Plug and PlayYes
Weight & dimensions
Width58 mm
Depth90 mm
Height20 mm
Weight43 g
Logistics data
Harmonized System (HS) code84733020
Products per master (outer) case28 pc(s)
Master (outer) case width331 mm
Master (outer) case length504 mm
Master (outer) case height237 mm
Packaging data
Cables includedFireWire
Mounting brackets includedYes
ManualYes
Package width175 mm
Package depth144 mm
Package height32 mm
Package weight200 g
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-20 - 90 °C
Operating relative humidity (H-H)0 - 90%
Technical details
Sustainability complianceYes
Compliance certificatesCE, RoHS
Ports & interfaces
Host interfacePCIe
Output interfaceIEEE 1394/Firewire
Expansion card standardPCIe 1.1
Firewire (IEEE 1394) ports3
FireWire 400 ports quantity1
FireWire 800 ports quantity2
Design
InternalYes
Product colourGreen
Mean time between failures (MTBF)149905 h
Hot-swapYes
System requirements
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 11, Windows 11 x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Linux operating systems supportedYes
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2019
