SkyHawk™ leverages Seagate's extensive experience in designing drives purpose-built for surveillance applications.
ImagePerfect™ firmware is designed to ensure seamless video footage capture in 24×7 surveillance workloads1 that record video from 64 HD cameras.
SkyHawk Health Management actively helps protect your surveillance storage by focusing on prevention, intervention, and recovery options.2 Included is RAID RapidRebuild™, which provides 3× faster volume rebuilds over traditional RAID rebuilds.
Unparalleled data protection with included 3-year Rescue Data Recovery Services plan, helping protect important video data with Seagate's in-house data recovery services.
RV sensors built in allow drives to maintain performance in multi-bay systems, giving customers the flexibility to scale their systems when more storage is needed.
ATA streaming support enables recordings from up to 64 HD cameras for smooth, uninterrupted footage.
1 M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions. Tarnish-resistant components help protect drive from environmental elements, increasing field reliability
Products specifications
| HDD capacity | 1 TB |
| Storage drive buffer size | 256 MB |
| HDD size | 3.5" |
| Interface | Serial ATA III |
| Type | HDD |
| Component for | PC |
| HDD interface transfer rate | 6 Gbit/s |
| HDD sustained transfer rate | 180 MiB/s |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^14 bits read |
| Rotational Vibration (RV) sensors | Yes |
| 24/7 operation | Yes |
| RV sensor(s) | Yes |
| Start/stop cycles | 600000 |
| Workload rate limit | 180 TB/year |
| Mean time between failures (MTBF) | 1000000 h |
| Width | 101.6 mm |
| Height | 147 mm |
| Depth | 20.2 mm |
| Weight | 415 g |
| Maximum number of cameras supported | 64 |
| Operating temperature (T-T) | 0 - 65 °C |
| Power consumption (typical) | 3.7 W |
| Power consumption (off) | 0.25 W |
| Power consumption (idle) | 2.5 W |
| Operating voltage | 5 / 12 V |
| Start-up current | 1.8 A |
