Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Building Wiring Fault Indicator
This LED informs users of potentially dangerous wiring problems in the wall circuit.
Cold-start capable
Provides temporary battery power when the utility power is out.
Dataline surge protection
Provides protection of connected equipment from power surges on the data lines.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Simple battery replacement
Increases UPS availability by allowing quick, easy battery replacement.
Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.
USB connection
Use your PC to access additional power protection and management features for your UPS via a USB Port.
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Products specifications
| UPS topology | Standby (Offline) |
| Output power capacity | 0.65 kVA |
| Output power | 400 W |
| Waveform | Sine |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 230 V |
| Input frequency | 47/63 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 230 V |
| Output frequency | 47/63 Hz |
| Maximum current | 6 A |
| Surge energy rating | 310 J |
| Efficiency | 80% |
| Noise level | 45 dB |
| Surge protection | Yes |
| Surge protection features | Digital Subscriber Line (DSL) |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| Width | 130 mm |
| Depth | 365 mm |
| Height | 120 mm |
| Weight | 4 kg |
| Harmonized System (HS) code | 85078000 |
| Package width | 186 mm |
| Package depth | 441 mm |
| Package height | 190 mm |
| Package weight | 4.5 kg |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Non-operating altitude | 0 - 4500 m |
| Compliance certificates | RoHS |
| Certification | CE, EAC |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100Base-T |
| Form factor | Compact |
| Cable length | 1.83 m |
| Product colour | Black |
| LED indicators | Yes |
| Manual | Yes |
| Battery life (max) | 5 year(s) |
| Battery recharge time | 16 h |
| Hot-swap battery | Yes |
| Automatic battery test | Yes |
| Cold start | Yes |
